ERF5-020-07.0-L-DV-TR

Name: Samtec ERF5-020-07.0-L-DV-TR
Brand: Samtec
SKU: 200-ERF502007.0LDVTR
Price: 6.77 CAD
Availability: InStock

Images are for reference only
See Product Specifications

Mouser #:

200-ERF502007.0LDVTR

Mfr. #:

ERF5-020-07.0-L-DV-TR

Mfr.:

Samtec

Description:

Board to Board & Mezzanine Connectors 0.50 mm Edge Rate Rugged High Speed Socket

Datasheet:

ERF5-020-07.0-L-DV-TR Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about ECAD Model.

More Information

Learn more about Samtec ERF5-020-07.0-L-DV-TR

In Stock: 498

Stock:: 498 Can Ship Immediately

An unexpected error occurred. Please try again later.
Factory Lead-Time:: 1 Week Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

$-.--

Ext. Price:

$-.--

Est. Tariff:

Pricing (CAD)

Qty.	Unit Price	Ext. Price
	$6.77	$6.77
	$6.26	$156.50
	$5.89	$294.50
	$5.61	$561.00
Full Reel (Order in multiples of 400)
	$5.61	$2,244.00
	$5.04	$4,032.00
	$4.53	$10,872.00
	$3.63	$17,424.00

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Samtec
Product Category:	Board to Board & Mezzanine Connectors
RoHS:
Product:	Sockets
Number of Positions:	40 Position
Pitch:	0.5 mm (0.02 in)
Number of Rows:	2 Row
Termination Style:	Solder
Mounting Angle:	Vertical
Stack Height:	9 mm, 11 mm, 12 mm
Maximum Data Rate:	56 Gbps
Minimum Operating Temperature:	- 55 C
Maximum Operating Temperature:	+ 125 C
Contact Plating:	Gold
Contact Material:	Phosphor Bronze
Housing Material:	Liquid Crystal Polymer (LCP)
Series:	ERF5
Packaging:	Reel
Packaging:	Cut Tape
Brand:	Samtec
Flammability Rating:	UL 94 V-0
Mounting Style:	Mounting Peg
Product Type:	Board to Board & Mezzanine Connectors
Factory Pack Quantity:	400
Subcategory:	Board to Board & Mezzanine Connectors
Tradename:	Edge Rate
