173107-0074

Name: Molex 173107-0074
Brand: Molex / FCT
SKU: 152-FM11W1S1-K121
Price: 13.49 CAD
Availability: InStock

Images are for reference only
See Product Specifications

Mouser #:

152-FM11W1S1-K121

Mfr. #:

173107-0074

Mfr.:

Molex / FCT
Molex / FCT

Description:

D-Sub Mixed Contact Connectors 11 POS PCB SKT 11W1 10PIN 1 HOLE

Datasheet:

173107-0074 Datasheet

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about ECAD Model.

More Information

Learn more about Molex / FCT 173107-0074

In Stock: 121

Stock:: 121 Can Ship Immediately

An unexpected error occurred. Please try again later.
Factory Lead-Time:: 22 Weeks Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

$-.--

Ext. Price:

$-.--

Est. Tariff:

Pricing (CAD)

Qty.	Unit Price	Ext. Price
	$13.49	$13.49
	$10.55	$527.50
	$10.37	$10,370.00
2,500	Quote

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Molex
Product Category:	D-Sub Mixed Contact Connectors
RoHS:
REACH - SVHC:
Contact Arrangement:	11W1
Number of Positions:	10 Position
Brand:	Molex / FCT
Contact Plating:	Gold
Current Rating:	5 A
Filtered:	Unfiltered
Gender:	Female
Number of Rows:	2 Row
Product Type:	Mixed Contact D-Sub Connectors
Series:	173107
Shell Size:	15P
Factory Pack Quantity:	50
Subcategory:	D-Sub Connectors
Voltage Rating:	1 kV
Part # Aliases:	FM11W1S1-K121 01731070074
Unit Weight:	7.300 g

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Filter Document:

Datasheet

173107-0074 Datasheet

RoHS Certificate (PDF)

CAHTS:: 8536690020
CNHTS:: 8536901100
USHTS:: 8536694040
JPHTS:: 853669000
KRHTS:: 8536691000
TARIC:: 8536693000
MXHTS:: 8536699999
BRHTS:: 85366990
ECCN:: EAR99

D-Sub Connectors

FCT D-Sub Connectors are illustrated in many sizes for various applications. These connectors are available in standard, high-density, mixed layout, waterproof, backshells, hardware, and other D-Sub connector variants. Each of these variants is built using various materials, alloys, and with high-quality heat-resistant plastics.

Mixed Layout D-Sub Connectors

FCT Mixed Layout D-Sub Connectors are designed so that any FCT connector can be installed in any other contact arrangement from FCT. This includes 75Ω and 50Ω coaxial contacts, high-power contacts up to 40A, high-voltage contacts up to 3kV, and pneumatic contacts. These mixed layout D-sub connectors feature high abrasion and corrosion resistance, low thermal contact resistance, good contact characteristics, solderability, and plating density. Depending on the application, solder pot, straight PCB, or crimp terminations are available. The insertion and removal tools for the crimp versions ensure safe, reliable installation.
